4ETO-500 Gas Sensor For Medical Sterilization Monitoring Industrial Safety Monitoring

प्रमाणन
चीन ShenzhenYijiajie Electronic Co., Ltd. प्रमाणपत्र
चीन ShenzhenYijiajie Electronic Co., Ltd. प्रमाणपत्र
मैं अब ऑनलाइन चैट कर रहा हूँ

4ETO-500 Gas Sensor For Medical Sterilization Monitoring Industrial Safety Monitoring

4ETO-500 Gas Sensor For Medical Sterilization Monitoring Industrial Safety Monitoring
4ETO-500 Gas Sensor For Medical Sterilization Monitoring Industrial Safety Monitoring 4ETO-500 Gas Sensor For Medical Sterilization Monitoring Industrial Safety Monitoring

बड़ी छवि :  4ETO-500 Gas Sensor For Medical Sterilization Monitoring Industrial Safety Monitoring

उत्पाद विवरण:
उत्पत्ति के प्लेस: सीएन
मॉडल संख्या: 4eto-500
भुगतान & नौवहन नियमों:
न्यूनतम आदेश मात्रा: 1pcs
मूल्य: विनिमय योग्य
पैकेजिंग विवरण: मानक पैकेजिंग
प्रसव के समय: 5 से 8 कार्यदिवस
भुगतान शर्तें: एल/सी, डी/ए, डी/पी, टी/टी, वेस्टर्न यूनियन, मनीग्राम
आपूर्ति की क्षमता: 5000 पीसी

4ETO-500 Gas Sensor For Medical Sterilization Monitoring Industrial Safety Monitoring

वर्णन
नाममात्र रेंज: 0 ~ 500 पीपीएम अधिकतम अधिभार: 1000 पीपीएम
संवेदनशीलता (20℃): 0.058 μ 0.033 μA/पीपीएम प्रतिक्रिया समय (T90): ≤ 120 एस
शून्य सिग्नल (20℃): - 0.2 ~ 2.5 μA आधार रेखा शिफ्ट (-20℃ ~ 50℃): <25 पीपीएम
प्रमुखता देना:

4ETO-500 medical sterilization gas sensor

,

industrial safety monitoring gas sensor

,

4ETO-500 gas sensor for sterilization



                    4ETO - 500 Gas Sensor For Medical Sterilization Monitoring Industrial Safety Monitoring



Product Applications:

The 4ETO-500 gas sensor is an electrochemical ethylene oxide (ETO) sensor primarily designed for:



  1. Medical Sterilization Monitoring
    • Detecting ETO leaks in hospital and clinical sterilization systems, suitable for fixed or portable detection equipment.
  2. Industrial Safety Monitoring
    • Applied in coal mines, chemical plants, and organic volatile gas monitoring to ensure production safety.
  3. Environmental & Storage Control
    • Used for ETO concentration detection in fruit storage environments to maintain freshness and safety.

Product Features:

  1. Wide Measurement Range
    • Nominal range: 0–500 ppm; maximum overload: 1,000 ppm, suitable for various ETO concentration detection scenarios.
  2. High Sensitivity
    • Sensitivity: 0.058 ± 0.033 μA/ppm, enabling precise detection of subtle ETO concentration changes.
  3. Rapid Response
    • Response time (T90): ≤120 seconds, ensuring timely feedback for leak alarms.
  4. Strong Environmental Adaptability
    • Operating temperature: -20°C–50°C; humidity: 15%–90% rh (non-condensing); pressure: 1 ± 0.1 atm, suitable for harsh industrial and indoor environments.
  5. Excellent Linearity
    • Linear output within 0–500 ppm, facilitating accurate data measurement and signal processing.
  6. Long Service Life
    • Expected operating life: 2 years in clean air (long-term output drift <2% signal/month); storage life: 6 months in original packaging, ensuring stability and reliability.
  7. Easy Installation & Replacement
    • Pin-to-pin replacement for standard 4-series ETO sensors from other manufacturers, allowing seamless integration into existing equipment designs.



Nominal Range 0 - 500 ppm
Maximum Overload 1,000 ppm
Sensitivity 0.058 ± 0.033 μA/ppm
Response Time (T90) ≤ 120 s
Zero Signal (20℃) - 0.2 - 2.5 μA
Baseline Shift (-20℃ - 50℃) < 25 ppm
Resolution 2 ppm
Linearity Linear up to 500 ppm
Bias Voltage +300 mV
Temperature Range - 20℃ - 50℃
Pressure Range 1 ± 0.1 atm
Humidity Range 15% - 90% rh (non - condensing)
Long - term Output Drift < 2% signal/month
Recommended Storage Temperature 10℃ - 30℃
Expected Operating Life 2 years in clean air
Storage Life 6 months in original packaging
Warranty 12 months
Max. Current at 1,000 ppm ETO < 0.2 mA
Max. O/C Voltage 1.3 V
Max. S/C Current < 1.0 A
Housing Material ABS
Weight (Nominal) 5 g
Orientation None
Output Signal Analog - type
Protection Level 6
Linearity 1(%F.S.)



4ETO-500 Gas Sensor For Medical Sterilization Monitoring Industrial Safety Monitoring 0
